Size | Model | |
Hidro-HP125V | Hidro-HP210VS | |
A | 855 | 955 |
G | 110 | 110 |
F | 320 | 320 |
Model No | Hidro-HP95V | Hidro-HP125V | Hidro-HP140V | Hidro-HP170V | Hidro-HP140VS | Hidro-HP170VS | Hidro-HP210VS | Hidro-HP260VS | |
50hz / 60hz R410A | |||||||||
COP(heating) | 4.8 | 4.9 | 4.9 | 4.8 | 4.9 | 4.8 | 4.9 | 4.9 | |
Heating capacity | W | 9500 | 12500 | 14000 | 17000 | 14000 | 17000 | 21000 | 26000 |
BTU | 32500 | 42500 | 48000 | 60000 | 48000 | 60000 | 73000 | 90000 | |
Heating Power | W | 1980 | 2550 | 2880 | 3500 | 2880 | 3500 | 4250 | 5300 |
COP(cooling) | 3 | 2.9 | 2.9 | 2.9 | 2.9 | 2.9 | 2.9 | 2.8 | |
Cooling Capacity | W | 6150 | 7700 | 8600 | 10300 | 8600 | 10300 | 13500 | 16000 |
BTU | 21000 | 26500 | 48000 | 35200 | 48000 | 35200 | 46000 | 55000 | |
Cooling Power | W | 2050 | 2650 | 2980 | 3600 | 2980 | 3600 | 4650 | 5730 |
Power Supply | V/Ph/Hz | 220V/1Ph/50hz and 60hz | 380v-440v/3Ph/50hz and 60hz | ||||||
Compressor Type | Rotary | Scroll | |||||||
Noise | Db(A) | 54 | 54 | 54 | 54 | 54 | 54 | 60 | 60 |
Water Connection | mm | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
Packing Size | mm | 700x740x1010 | 700x740x1110 | ||||||
N.W | kg | 75 | 91 | 105 | 108 | 105 | 108 | 111 | 112 |
G.W | kg | 80 | 98 | 113 | 120 | 113 | 120 | 123 | 125 |
Measuring Conditions
Heating:Dry bulb 24°C , wet bulb 19°C , water entering temperature 27°C .
Cooling:Dry bulb 35°C , wet bulb 24 °C, water entering temperature 27°C.
