- Produced in aluminum and zinc alloy which is durable and light.
- High temperature capacitors ensure a long life even in hot temperatures environments and continuous usage.
- Anticorrosive external treatment for outside use and corrosive environments.
- Suitable for swimming pool, SPA, aquaculture, chemical plant, pharmacy and lots of other industries.
- Available models from 0.75HP to 15HP and 110V to 440V.
- Optional accessories: inhale filter for particles or silencer to reduce the noise level up to 10dB only.
- Power cords are included in all single phase models.
Model | Frequency | HP | Power | Voltage | Current | Max.Air Pressure | Max.flux | Max Vacuum Degree | Rotary Speed | Noise |
Hz | kW | V | A | kPa | m3/hr | kPa | r/min | dB(A) | ||
AB075 | 50 | 0.75Hp | 0.55 | 220 | 4.8 | 20 | 110 | 16 | 2800 | <60 |
60 | 0.88Hp | 0.66 | 220 | 5.76 | 24 | 132 | 19 | 3400 | ||
AB075-110 | 60 | 0.88Hp | 0.66 | 110 | 11.52 | 24 | 132 | 19 | 3400 | |
AB075M | 50 | 0.75Hp | 0.55 | △220-Y380 | 2.51(1.45) | 20 | 110 | 16 | 2800 | |
60 | 0.88Hp | 0.66 | △220-Y380 | 3.01(1.74) | 24 | 132 | 19 | 3400 | ||
AB075M | 50 | 0.75Hp | 0.55 | △220-Y440 | 2.51(1.26) | 20 | 110 | 16 | 2800 | |
60 | 0.88Hp | 0.66 | △220-Y440 | 3.01(1.50) | 24 | 132 | 19 | 3400 |
